Description
The Cavazzo's frame design utilises a mix of Toray T500 and T700 carbon fibre to provide the perfect balance of strength, stiffness and weight. The dropped rear stays are designed to suit 1x or 2x drivetrains and the short chainstay length is perfect for agile handling. To suit the Cavazzo's go anywhere design, the frame has mudguards bosses with clearance for up to 50mm guards and tyre clearance for 700c x 45mm or 650b x 2.1" tyres.
Also fitted with rack mounts which have 15kg front and 25kg rear weight limits for all your touring or bike-packing equipment needs. 3 x bottle bosses for extra hydration or equipment, with additional fast fuel eyelets on the top tube.
Suitable for all electronic and mechanical groupsets with full Internal dropper post routing. Flat mount standard for hydraulic or mechanical disc brakes and 12mm thru-axles to keep everything stiff and secure.
Designed and assembled in the UK
Technical Specifications:
Sizes: S, M, L, XL
Frame: UD Toray T500 and T700 Carbon with mudguard, rack and 3 bottle cage mounts
Forks: Carbon UD 1-1/8" to 1-1/2" with mudguard eyelets and front rack mounts
Bottom Bracket: BSA Threaded
Brakes: Flat Mount Disc
Axles: 12x100mm Front, 12x142mm Rear
Seatpost Dia: 27.2mm
Max Tyre Clearance: 700x45c, 650b x 2.1" or 29x1.85"
Frame Weight: 1.2kg
Fork Weight: 460g
Bike Specifications:
Components: Shimano GRX 11x Hydraulic Disc
Chainset: Shimano GRX 11x Chainset 40T
Disc Brakes: Shimano GRX Hydraulic
Cassette Shimano SLX 11/42T
Chain: KMC 11x
Saddle: Selle Italia Model X
Bar: Tifosi Gravel Alloy
Stem/Seatpost: Tifosi Alloy
Wheelset: Vision Team 30 TLR Disc
Tyres: Impac CrossPac 700x38c
