Stem |
Alloy Trail Stem, 35mm bar bore |
Handlebars |
Alloy, 35mm diameter, 780mm width, 8-degree backsweep, 6-degree upsweep |
Tape |
Specialized Trail Grips |
Saddle |
Bridge Comp, Hollow Cr-mo rails, 155/143mm |
SeatPost |
X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9, S1: 100mm, S2: 125mm, S3: 150mm, S4/S5: 175mm, S6: 190mm |
Rear Derailleur |
SRAM GX Eagle, 12-speed |
Shift Levers |
SRAM GX, trigger, 12-speed |
Cassette |
Sram XG-1275, 12-speed, 10-52t |
Chain |
SRAM NX Eagle, 12 speed |
Chain |
SRAM NX Eagle, 12 speed |
Crankset |
Praxis Forged/Custom Offset/ISIS Spindle Interface, 160mm |
Chainrings |
SRAM X-Sync Eagle, 104 BCD, 32T, steel |
Rims |
Specialized 29, hookless alloy, 30mm inner width, tubeless ready |
Front Hub |
Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h |
Spokes |
DT Swiss Industry |
Inner Tubes |
Standard, Presta Valve |
Rear Hub |
Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h |
Front tire |
Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.6 |
Rear Tire |
Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, 27.5x2.6 |
Seat Binder |
Alloy, 38.6mm |
Frame |
Specialized M5 premium alloy, headset adjust, BB height adjust, S-Sizing, internal cable routing, 150mm travel, 148mm spacing |
Motor |
Specialized 2.2 Custom Rx Trail Tuned Motor |
UI/ Remote |
Specialized TCU, 10-LED State of charge, 3-LED Ride Mode display, ANT+/Bluetooth®, w/Handlebar remote |
Charger |
Custom charger, 42V4A w/ Rosenberger plug, 100-240V |
Battery |
Specialized M3-700, Integrated battery, 700Wh |
Wiring Harness |
Custom Specialized wiring harness |
Rear Shock |
S1: FOX DPS Performance Series, 3-position lever, rebound adjust, 52.5x210mm, S2-S6: FOX FLOAT X Performance, LSR, 2-position lever, 55x210mm |
Fork |
Fox Rhythm 36, S1: 150mm travel, S2-S6: 160mm travel |
Front Brake |
SRAM Code R, 4-piston caliper, hydraulic disc, S1-S3: 200mm, S4-S6: 220mm |
Rear Brake |
SRAM Code R, 4-piston caliper, hydraulic disc, 200mm |
