Frame | All new Levo 4 frame, 150mm travel, w/SWAT storage, side entry battery, fork travel up to 180mm |
Fork | Marzocchi Bomber Z1, 29", S2-S6: 160mm, S1: 150mm, sweep adjust compression |
Rear Shock | Marzocchi Bomber inline, S2-6: 210x55mm, S1: 210x52.5, low speed rebound adjust |
Stem | Alloy Trail Stem, 35mm bar bore |
Bars | 6061 mtn bars, 35mm diameter, 8 degree back sweep, 6 degrees up sweep, 800mm width. S1/S2: 30mm rise, S3-S6: 40mm rise |
Front Brake | SRAM DB8, 220mm rotor |
Rear Brake | SRAM DB8, 200mm rotor |
Shifters | SRAM Eagle 70 T-Type, single-click lever |
Speed | 12 |
Rims | Specialized 29, hookless alloy, 30mm inner width, tubeless ready |
Front Hub | Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h |
Rear Hub | Specialized Alloy Rear Hub Disc, Sealed Cardridge Bearings, 6-Bolt, 12X148mm Thru-Axle, 32H, Hd Steel Fhb |
Spokes | DT Swiss Industry |
Front Tyre | Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, TLR, 29x2.3" |
Rear Tyre | Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, TLR, 27.5x2.3" |
Seat Post | TranzX dropper, 34.9mm, S1: 100mm, S2: 125mm, S3: 150mm. S4-S5: 170mm, S6- 200mm |
Saddle | Body Geometry Bridge Saddle, steel rails |
Chainset | SRAM S1000 Crankset, Integrated Guard, 55mm Chainline, 155mm, 34T |
Chain | SRAM Eagle 70 T-Type 12-Speed |
Cassette | SRAM XS 1270 T-Type, 12-speed, 10-52t |
Battery Size (WH) | 840wh battery |
Motor | All New Specialized 3.1 Motor, 101Nm torque, 666W power |
User Interface | All New Mastermind TCU, 2.2" high res screen, fully customizable with Specialized app, Apple Find My integrated in display |
