Handlebar |
Merida Expert eTR; 780mm wide; 20mm rise |
Stem |
Merida Expert eTR II; aluminium; 35mm diameter; 0 degree rise - Stem length: 40mm (all sizes). GoPro & Supernova mount point. |
Headset |
Merida-8152 |
Pedal |
VP Components - VPE-527 |
Saddle |
Merida Expert CC with V-mount including Merida minitool |
SeatPost |
Merida Expert TR; 30.9mm diameter; in-line; Drop: 100mm (XS), 125mm (S), 150mm (M/L), 170mm (XL) |
Wheel size |
29" / 27.5 |
Rims |
Merida Expert TR; 29mm inner rim width; Aluminium; Tubeless ready (tubeless tape and valves not included) |
Spokes |
Black stainless |
Front Hub |
Shimano SLX; 110x15mm; 32 spokes; Center lock |
Rear Hub |
Shimano SLX; 148x12mm, 36 spokes; Center lock; including removable lever with 4/6mm Allen key |
Front tyre |
Maxxis Assegai; 29" x 2.5"; Kevlar bead; folding; TR EXO+ 3C MaxxGrip |
Rear tyre |
Maxxis DHR II; 27.5" x 2.6"; Kevlar bead, folding; 3C EXO+ TR |
Season |
2023 |
Frame |
Lite III - Hydroformed 6061 Double butted aluminium with intergrated battery. Internal cable routing via Smart entry ports. Tapered head tube, 148 x 12mm axle standard. Max. tyre size 27.5" x 2.8 |
Motor |
Shimano Steps EP6; 85Nm |
Battery |
Shimano EN806; 630Wh internal battery |
Battery capacity |
630Wh |
EBIKE DISPLAY |
Shimano SC-EN600 |
Charger |
Shimano EC-E8004; 4A Charging current |
Power button |
Shimano satellite system on/off; EW-SW300 |
Mode switch |
Shimano SW-EN600-L |
Shock |
FOX Float X P-S A Performance; platform |
Fork |
Marzocchi Z1 Ebike+; Air; 160mm travel; Tapered; 51mm fork offset. Max. tyre size: 29" x 2.6 |
Gears |
12 |
Shifters |
Shimano Deore SL-M6100 12 speed with Shimano SL -MT500-IL lever |
Rear Derailleur |
Shimano XT RDM8100 Shadow+ 12 speed |
Bottom Bracket |
Part of Shimano Steps motor |
Chain |
KMC e12T EPT |
Chainset |
Shimano CRE80-12-B; 34 tooth chainring with Shimano FCEM600; 165mm length crank |
Cassette |
Shimano M6100; 10-51 teeth; 12 speed |
Brake Lever |
Shimano SLX |
Front Brake |
Shimano SLX 4 piston hydraulic disc brake caliper with Shimano RT64 203 mm rotor |
Rear Brake |
Shimano SLX 4 piston hydraulic disc brake caliper with Shimano RTEM600 203 mm rotor |
Grip |
Merida Expert EC |
