| Frame |
CF2 carbon, gravel geometry for stable but nimble handling. Tapered head tube and 12 mm bolt though axles for stiffness and steering precision. Internal cable routing, Max tyre - 700x38c or 650bx45c |
| Fork |
Silex CF2; Full carbon; tapered steerer, 100 x 12mm axle standard; Max. tyre size: 700 x 38c / 650b x 45c |
| Gears |
20 |
| Shifters |
Shimano GRX400 |
| Front Derailleur |
Shimano GRX400 |
| Rear Derailleur |
Shimano GRX400 |
| Bottom Bracket |
FSA 386-BB30 PF6000 [SMN FC] |
| Chain |
KMC X10 |
| Chainset |
Shimano GRX600; 46-30 tooth chainset. Crank length: 170mm (XS,S), 172.5mm (M), 175mm (L,XL) |
| Cassette |
Shimano CS-HG50; 11-36 teeth; 10 speed |
| Brake Lever |
Shimano GRX400 |
| Front Brake |
Shimano GRX400; hydraulic disc brake caliper with Shimano RT10; 160mm rotor |
| Rear Brake |
Shimano GRX400; hydraulic disc brake caliper with Shimano RT10; 160mm rotor |
| Grip |
Merida Road Expert |
| Handlebar |
Merida Expert GR; aluminium; Width: 400mm (XS-S), 420mm (M), 440mm (L/XL) |
| Stem |
Merida Expert CW; aluminium; 31.8mm diameter; -8 degree rise - Stem length: 80mm (all sizes) |
| Headset |
Silex Neck |
| Saddle |
Merida Comp SL; V-mount; including Merida minitool |
| SeatPost |
Merida Expert CC; carbon; 30.9mm diameter; in-line |
| Wheel size |
700c |
| Rims |
Merida Comp SL; 17mm inner rim width; 22mm depth; Aluminium |
| Spokes |
Black stainless |
| Front Hub |
VP CLK170F; 100x12mm; 32 spokes; Center lock |
| Rear Hub |
VP CLK270R; 142x12mm; 32 spokes; Center lock. With Merida Expert SL axle; including removable lever; 6/4mm allen key |
| Front tyre |
Maxxis Rambler; 700 x 38c; Kevlar bead, folding; TR; EXO |
| Rear tyre |
Maxxis Rambler; 700 x 38c; Kevlar bead, folding; TR; EXO |
| Colour |
Red / Black |
| Season |
2023 |
