| Frame |
TFS - 6061 aluminium tubing, double butted and technoformed. BSA BB standard, 9mm QR axle standard. Replaceable dropout. Maximum tyre clearance 24" x 2.4 |
| Fork |
Merida Matts J. 24+; Material: aluminium. Max tyre size: 24" x 2.4 |
| Gears |
8 |
| Shifters |
Altus |
| Rear Derailleur |
Shimano RD-M310 |
| Bottom Bracket |
Cartridge Bearing |
| Chain |
Sunrace M84 |
| Chainset |
Merida Expert JR; 28 tooth chainset. Crank length: 140mm |
| Cassette |
Sunrace CSM558; 11-34 teeth; 8 speed |
| Brake Lever |
Power DS-100HT |
| Front Brake |
Power DS-100HT 2 piston hydraulic disc brake caliper with 160mm rotor |
| Rear Brake |
Power DS-100HT 2 piston hydraulic disc brake caliper with 140mm rotor |
| Grip |
Merida Expert JR |
| Handlebar |
Merida Expert JR; aluminium; 620mm width; 20mm rise |
| Stem |
Merida Expert CC; aluminium; 31.8mm diameter; -5 degree stem angle - Stem length: 60mm |
| Headset |
VP Z104AE |
| Pedal |
Marwi SP-202 |
| Saddle |
Merida Expert JR |
| SeatPost |
Merida CC; aluminium; 30.9mm diameter; in-line |
| Wheel size |
24 |
| Rims |
Merida JR 24+; Aluminium |
| Spokes |
Black steel |
| Front Hub |
Joytech D761DSE; 100x9mm; 24 spokes |
| Rear Hub |
Joytech D762TSE; 135x9mm; 24 spokes |
| Front tyre |
CST Jet C1820; 24" x 2.4"; wire bead |
| Rear tyre |
CST Jet C1820; 24" x 2.4"; wire bead |
| Season |
2023 |
| Other |
Centre mount kick stand |
