Frame |
TFS III - 6061 aluminium, double butted and technoformed. Tapered head tube. Chain stay mounted disc brake. Internal cable routing. Mudguard and kick stand mounts. BSA threaded BB. 135mm x 9mm axle. Max. tyre size 27.5" x 2.25 |
Fork |
Suntour XCT30; Coil; 100mm travel. Max. tyre size: 27.5" x 2.25 |
Gears |
24 |
Shifters |
Shimano ST-EF505 |
Front Derailleur |
Shimano FD-TY700 |
Rear Derailleur |
Shimano RD-M310 |
Bottom Bracket |
FSA TH-7420ST-W, Cartridge Bearing |
Chain |
Sunrace M84 |
Chainset |
Shimano TY301; 42-34-24 tooth chainset. Crank length: 170mm (XS,S), 175mm (M,L) |
Cassette |
Sunrace CSM558AU; 11-32 teeth; 8 speed |
Brake Lever |
Shimano ST-EF505 |
Front Brake |
Power DS-100HT; 2 piston hydraulic disc brake caliper with Shimano RT10; 160mm rotor |
Rear Brake |
Power DS-100HT hydraulic disc brake caliper with Shimano RT10; 160mm rotor |
Grip |
Merida EC |
Handlebar |
Merida CC; aluminium; 690mm wide; 15mm rise |
Stem |
Merida CC; aluminium; 31.8mm diameter; 6 degree rise - Stem length: 70mm (S), 80mm (M), 90mm (L), 100mm (XL), 110mm (XXL) |
Headset |
Merida M2345 |
Pedal |
VP Components, VPE-891 |
Saddle |
Merida Sport comfort |
SeatPost |
Merida CC; aluminium; 30.9mm diameter; 15mm lay back |
Wheel size |
27.5 |
Rims |
Merida CC; 17mm inner rim width; aluminium |
Spokes |
Steel UCP |
Front Hub |
Shimano TX505; 100x9mm; 32 spokes; Center lock |
Rear Hub |
Shimano TX505; 135x9mm; 32 spokes; Center lock |
Front tyre |
Merida K1080; 27.5" x 2.2"; wire bead |
Rear tyre |
Merida K1080; 27.5" x 2.2"; wire bead |
